Dual-Band Wi-Fi 5 Industrial Motherboard – Qualcomm IPQ4019
Product Overview
A high-performance dual-band Wi-Fi 5 industrial motherboard based on Qualcomm IPQ4019 + QCA8075 chipset. Features 2×2 MIMO on both 2.4 GHz (802.11n) and 5 GHz (802.11ac Wave 2.0), delivering up to 1750 Mbps combined throughput. Supports OpenWrt open platform, MU-MIMO, and flexible power input (DC 9-48V or PoE). Designed for enterprise wireless access, hospitality networks, and industrial IoT deployments.
Key Overview
Target Users：Enterprise network integrators, hospitality WiFi solution providers, industrial automation OEMs, and system builders requiring compact dual-band wireless modules.
Core Strengths：Dual-band 802.11ac Wave 2.0 (1750 Mbps total), Qualcomm IPQ4019 industrial-grade chipset, OpenWrt support, flexible power input (DC or PoE), compact Mini-ITX form factor.
Typical Applications：Enterprise wireless access points, hospitality networks (hotels, cafes, restaurants), retail chains, healthcare and education campuses, industrial IoT gateways, and MESH networking nodes.
WiFi Standard：802.11ac Wave 2.0 / 802.11n
Interface：1000M RJ45 x2, USB, SD
Technical Specifications
The table below outlines the complete hardware and wireless specifications for this dual-band industrial motherboard.
Core Hardware
| Parameter | Specification |
|---|---|
| CPU | Qualcomm IPQ4019 + QCA8075 |
| DDR | 256 MB |
| FLASH | 32 MB NOR Flash |
| Bootloader | Fail-safe Web U-Boot |
| Dimensions | 106 x 80 x 17 mm |
| Weight | 56 g |
Wireless Specifications
| Parameter | Specification |
|---|---|
| Wireless Standards | 802.11ac Wave 2.0 (5 GHz), 802.11n (2.4 GHz) |
| MIMO Configuration | 2×2 MIMO on each band |
| Frequency Bands | 2412-2462 MHz (2.4 GHz), 5180-5825 MHz (5 GHz) |
| Channel Bandwidth | 20 MHz / 40 MHz / 80 MHz (configurable) |
| Max Data Rate | 1750 Mbps combined (5 GHz: up to 1300 Mbps + 2.4 GHz: up to 450 Mbps, Typical) |
| Transmit Power | 5 GHz: 23 dBm x2; 2.4 GHz: 23 dBm x2 (Typical, per regional regulations apply) |
| Modulation | BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM |
| Wireless Optimization | MU-MIMO, TDMA, Seamless Roaming support |
Power and Interface
| Parameter | Specification |
|---|---|
| Power Supply | DC: 9-48 V; PoE: 15-24 V or 48 V (select one) |
| Power Consumption | Average 8 W (complete unit, Typical) |
| Ethernet Ports | 2x 1000M RJ45 |
| Internal Interfaces | DC x1, USB x1, E-JA x1, U.FL x4, SD card slot x1, GPIO expansion, TTL debug interface |
Environmental and Software
| Parameter | Specification |
|---|---|
| Operating Temperature | -20C to +65C |
| Operating Humidity | 5% to 95% (non-condensing) |
| System | OpenWrt, MESHCOM, Web U-Boot |
| Configuration Method | Web-based management interface |
Key Features
Dual-Band 802.11ac Wave 2.0
Simultaneous 2.4 GHz (450 Mbps) and 5 GHz (1300 Mbps) operation delivers 1750 Mbps combined throughput. 2×2 MIMO on each band handles multiple clients without bandwidth bottlenecks.
Qualcomm IPQ4019 Industrial Chipset
Built on Qualcomm IPQ4019 SoC with QCA8075 PHY – a proven enterprise-grade platform with robust driver support and long-term stability. Supports MU-MIMO for efficient multi-user throughput.
OpenWrt Support
Pre-installed OpenWrt enables flexible software customization, advanced routing, firewall rules, and third-party package installation. Web U-Boot provides fail-safe recovery and easy firmware updates.
Flexible Power Input
Accepts DC input (9-48 V) or PoE (15-24 V / 48 V). Dual power options simplify integration into existing infrastructure without requiring separate power adapter installations.
Compact Mini-ITX Form Factor
Measures just 106 x 80 x 17 mm and weighs 56 g. Fits into space-constrained enclosures for wall-mounted APs, ceiling installations, or embedded IoT gateway designs.
Enterprise Wireless Features
TDMA and seamless roaming support ensure smooth handoff in large-scale deployments. WAPI support (with optional crypto chip) meets Chinese wireless security standards for government and enterprise networks.
Target Applications
- Enterprise wireless access points – Dual-band 1750 Mbps handles dense client deployments in office buildings, meeting rooms, and conference centers
- Hospitality networks – Hotels, guesthouses, cafes, and restaurants benefit from seamless roaming and reliable coverage across multiple floors or large open areas
- Retail chains – Supports point-to-multipoint topology for connecting multiple store locations to a central hub with sufficient bandwidth for POS systems and inventory management
- Healthcare and education – Campus-wide wireless coverage with MESH networking capability for lecture halls, dormitories, and hospital wings
- Industrial IoT gateways – Compact form factor and wide temperature range (-20C to +65C) enable deployment in warehouse and factory environments
- MESH networking nodes – OpenWrt-based MESHCOM support enables self-organizing network topologies for municipal wireless projects and temporary event coverage
Frequently Asked Questions
Q: Does this motherboard support PoE out to power downstream devices?
No – this board supports PoE input only (15-24 V or 48 V passive PoE). It does not provide PoE output. For deployments requiring PoE downstream (e.g., IP cameras), consider adding a PoE splitter or using a separate PoE switch.
Q: Can I install custom packages on OpenWrt?
Yes – the board runs standard OpenWrt with full package manager (opkg) support. You can install additional packages for VPN, QoS, monitoring, or custom applications. Note that flash storage is limited to 32 MB, so storage-intensive packages may require external USB storage.
Q: What antenna connectors does this board use?
The board has 4x U.FL (IPEX) antenna connectors – 2 for the 2.4 GHz radio and 2 for the 5 GHz radio (supporting 2×2 MIMO on each band). U.FL to SMA or N-type pigtail cables are typically used to connect external antennas.
Q: Is this board compatible with Mesh networking?
Yes – the board supports MESHCOM protocol (pre-installed on OpenWrt) for self-organizing MESH networks. It also supports standard 802.11s MESH and BATMAN-adv for interoperability with other MESH-capable devices.
Q: What is the maximum range of this board?
Range depends heavily on antenna selection, installation height, and environmental obstacles. With standard omnidirectional antennas (3-5 dBi), expect 50-100 m coverage in open office environments. High-gain sector antennas (10-15 dBi) can extend coverage to 200-500 m in point-to-multipoint setups.
Q: Does this support 802.11ax (WiFi 6)?
No – this board supports 802.11ac Wave 2.0 (WiFi 5) and 802.11n (WiFi 4). For WiFi 6 / 802.11ax tri-band solutions (2.4 GHz + 5 GHz + 6 GHz), consider boards based on Qualcomm Networking Pro 600/800 series or MediaTek Filogic series.
