Key Overview

Who this is for: Embedded hardware engineers, procurement managers and OEM product teams already running Compex Wi-Fi modules who need a qualified second source — for supply redundancy, cost, customization or OEM branding.

Core Issue: Single-sourcing a radio module is a long-term risk, but most engineers assume switching means a board respin and a driver rewrite. It usually doesn’t — provided four parameters line up.

Key Conclusions: Zukaka builds drop-in Compex replacements across every generation — Wi-Fi 5 (WLE1216VX, QCA9984/QCA9994), Wi-Fi 6 and 6E (WLE3000HX, WLE3002HX, WLW3000H6), and Wi-Fi 7 (WLE7000, WLTB7000, WLTE7000 series). Same Qualcomm chipsets, same reference designs (CAS03, PN02.1, PN02.6, WK01.5, WK03.2), same pinouts, same ath10k/ath11k/ath12k drivers. Switching a Compex module for a Zukaka one normally needs no hardware or software change — what changes is that you gain a second source, ODM customization and OEM branding.

Keywords: Compex Wi-Fi module alternative, drop-in replacement, WLE1216VX alternative, WLE3000HX replacement, WLE7002E55 alternative, Qualcomm Wi-Fi module

Can you replace a Compex module with another brand?

Key Takeaway: Yes — but only if four parameters match. Substituting on chipset alone is the single most common cause of a failed replacement.

A Wi-Fi module is not a generic part you can swap on brand name alone. It is a radio, a mechanical interface, a thermal solution and a driver contract all at once. Miss any one of the four parameters below and the swap fails — usually at the worst possible moment, which is after you have already built boards.

# Parameter Why it matters What happens if mismatched
1 Chipset / platform Sets generation, MIMO ceiling, driver family and certification path Module not recognised; existing device certification invalidated
2 Form factor Mini PCIe and M.2 are mechanically and electrically different Will not physically mount
3 Key edge M.2 E-key, A+E-key and B+M-key are notched differently Will not seat; forcing it can damage the connector
4 RF front-end PA, LNA, filter and diplexer set real TX power and band support Range and throughput fall; band tests fail

There is a fifth parameter that matters more in industrial and outdoor products than any of the four above, and it is the one buyers most often forget:

5 Operating temperature Commercial grade is −20 to +70 °C; industrial (I-Temp) is −40 to +85 °C A module that matches electrically but is rated to +70 °C will fail in a sealed outdoor enclosure that reaches +85 °C internally in summer

Industrial temperature is not a badge you add for marketing. It decides which enclosure you can ship and which markets you can sell into. If the device sits in the sun, on a pole, or inside a fanless housing, specify I-Temp — and then verify sustained throughput at the rated upper temperature, not just at room temperature on a bench.

Full Compex to Zukaka cross-reference

Key Takeaway: Every major Compex module across Wi-Fi 5, 6, 6E and 7 has a Zukaka equivalent in the same form factor, on the same Qualcomm chipset, built from the same reference design.

These tables are the complete mapping. Confirm against the exact part number before you order — band plans occasionally shift between hardware revisions.

Wi-Fi 7 — WLE7000 series (Mini PCIe)

Built on Qualcomm’s Waikiki reference designs (WK01.5, WK03.2). The four WLE7002 parts are 2×2:2 dual-band concurrent; the three WLE7000E parts dedicate all four chains to a single band.

Compex Module Zukaka Alternative Chipset Band Config TX Power Power
WLE7002E25 ZK-WLE7002E25 QCN6224 / QCN9274 2.4 + 5 GHz DBDC 20 / 18 dBm 8W
WLE7002E26 ZK-WLE7002E26 QCN6274 / QCN9274 2.4 + 6 GHz DBDC 20 / 17 dBm 8.3W
WLE7002E55 ZK-WLE7002E55 QCN6274 / QCN9274 5 + 6 GHz DBDC 18 / 18 dBm 8.7W
WLE7002E56 ZK-WLE7002E56 QCN6274 / QCN9274 2.4 + 6 GHz DBDC 20 / 17 dBm 8.3W
WLE7000E2 ZK-WLE7000E2 QCN6224 / QCN9274 2.4 GHz only, 4×4:4 20 dBm 8W
WLE7000E5 ZK-WLE7000E5 QCN6224 / QCN6274 / QCN9274 5 GHz only, 4×4:4 18 dBm 8.5W
WLE7000E6 ZK-WLE7000E6 QCN6274 / QCN9274 6 GHz only, 4×4:4 17 dBm 9.3W

Wi-Fi 7 — WLTB7000 and WLTE7000 series (M.2)

Two distinct M.2 form factors. WLTB7000 sits in M.2 2230 Key E (PCIe 3.0 x1) and is the smallest option. WLTE7000 sits in M.2 3042 Key B (PCIe 3.0 x2 or x4), which buys you more PCB area for thermal dissipation and a screw mount that survives vibration.

Compex Module Zukaka Alternative Form Factor Band Config Chipset
WLTB7002E25 ZK-WLTB7002E25 M.2 2230 Key E 2.4 + 5 GHz DBDC QCN6224 / QCN6274 / QCN9274
WLTB7002E26 ZK-WLTB7002E26 M.2 2230 Key E 2.4 + 6 GHz DBDC QCN6274 / QCN9274
WLTB7002E55 ZK-WLTB7002E55 M.2 2230 Key E 5 + 5 GHz DBDC QCN6274 / QCN9274
WLTB7002E56 ZK-WLTB7002E56 M.2 2230 Key E 5 + 6 GHz DBDC QCN6274 / QCN9274
WLTE7002E25 ZK-WLTE7002E25 M.2 3042 Key B 2.4 + 5 GHz DBDC QCN6224 / QCN6274 / QCN9274
WLTE7002E26 ZK-WLTE7002E26 M.2 3042 Key B 2.4 + 6 GHz DBDC QCN6274 / QCN9274
WLTE7002E55 ZK-WLTE7002E55 M.2 3042 Key B 5 + 6 GHz DBDC QCN6274 / QCN9274
WLTE7002E56 ZK-WLTE7002E56 M.2 3042 Key B 5 + 6 GHz DBDC QCN6274 / QCN9274
WLTE7000E2 ZK-WLTE7000E2 M.2 3042 Key B 2.4 GHz 4×4:4 QCN6224 / QCN9274
WLTE7000E5 ZK-WLTE7000E5 M.2 3042 Key B 5 GHz 4×4:4 QCN6224 / QCN6274 / QCN9274
WLTE7000E6 ZK-WLTE7000E6 M.2 3042 Key B 6 GHz 4×4:4 QCN6274 / QCN9274

Wi-Fi 6 and Wi-Fi 6E — WLE3000 series and WLW3000

Built on Qualcomm’s Pine reference designs (PN02.1, PN02.6). All three use the ath11k driver and are specified across the full industrial range.

Compex Module Zukaka Alternative Form Factor Chipset Key Specs
WLE3000HX ZK-WLE3000HX Mini PCIe QCN9024 / QCN9074 4×4:4, 2.4 or 5 GHz, 1.37 / 4.8 Gbps, 20 dBm, 9W, −40 to +85 °C
WLE3002HX ZK-WLE3002HX Mini PCIe QCN6024 / QCN9024 / QCN9074 2×2:2, 573 Mbps / 2.4 Gbps, 19 / 20 dBm, 6.6W, −40 to +85 °C
WLW3000H6 ZK-WLW3000H6 M.2 2230 Key E QCN9024 / QCN9074 Wi-Fi 6E, 6 GHz 4×4:4, 4.8 Gbps, 20 dBm, −40 to +85 °C

Wi-Fi 5 (802.11ac Wave 2) — WLE1216VX

Built on Qualcomm’s CAS03 reference design, and still the workhorse of outdoor CPE. Two grades, distinguished only by operating temperature.

Compex Module Zukaka Alternative Chipset Band TX Power Operating Temp
WLE1216VX (standard) ZK-WLE1216VX QCA9984 2.4 + 5 GHz, 4×4:4 20 dBm (2.4G) / 19 dBm (5G) −20 to +70 °C
WLE1216VX I-Temp ZK-WLE1216VX-I QCA9994 2.4 + 5 GHz, 4×4:4 20 dBm (2.4G) / 19 dBm (5G) −40 to +85 °C

Specialist modules — SDIO and Wi-Fi plus BLE combo

Two classes sit outside the generation tables, because you pick them for a physical or coexistence constraint rather than a throughput number.

Class Interface Streams The constraint it solves
Tiny SDIO card SDIO 3.0 1×1 Millimetre-scale embeds — IP cameras, handheld scanners — where the host has no spare PCIe controller
Wi-Fi + BLE combo M.2 or soldered 2×2 Gateways running a Wi-Fi uplink and a BLE sensor mesh in one chassis on a shared 2.4 GHz band
Real-World Example: A European industrial gateway vendor had a Mini PCIe slot squeezed between a DIN-rail clip and an M12 connector, with 14 mm of vertical clearance. A standard Mini PCIe card needed 4.5 mm above the connector for the U.FL pigtails alone. Moving to the M.2 2230 footprint freed the height, and the diplexer on the WLTB7002E25 kept the antenna count at two instead of four — which also removed a cable routing problem through the enclosure wall.

Why engineers switch from Compex to Zukaka

Key Takeaway: Five reasons come up again and again: supply diversification, ODM customization, OEM branding, dedicated engineering support and volume pricing. None of them involve giving up RF performance, because both suppliers build on the same Qualcomm reference designs.
  • Supply chain diversification. Dual-sourcing is standard practice in industrial hardware. Qualifying Zukaka as a second source gives you a fallback when lead times stretch or allocation tightens — without requalifying your whole design.
  • ODM customization. Compex offers limited customization. Zukaka runs full ODM: custom PCB shape and dimensions, an RF front-end tuned to your specific antenna and enclosure, custom firmware features, and connector placement. This is what you need when no catalogue module fits your mechanical envelope.
  • OEM branding. Zukaka modules can carry your brand — custom labels with your logo and part number, custom packaging, custom documentation. For OEMs shipping branded equipment, it removes third-party module visibility from the finished product.
  • Dedicated FAE support. One field application engineer is assigned per project, from spec review through certification. That shortens design-in and cuts integration risk.
  • Same Qualcomm silicon, same reference designs. QCN9274, QCN9074, QCN9024, QCN6024, QCA9994, QCA9984 — identical chipsets, identical reference designs. RF behaviour, driver compatibility, thermal profile and certification pathway all carry over.

Zukaka vs Compex at a glance

This table compares the two suppliers on the dimensions that affect an actual purchasing decision — not on specifications, which are equivalent.

Attribute Compex Zukaka
Wi-Fi generations 5, 6, 6E, 7 5, 6, 6E, 7
Chipset source Qualcomm reference designs Same Qualcomm reference designs
Portfolio size ~30+ models Matching portfolio, all major models
Customization (ODM) Limited standard options Full ODM: custom PCB, RF tuning, firmware
OEM branding Compex branding only Custom branding, labels, packaging
Engineering support Standard support Dedicated FAE per project
Sample lead time Standard lead time 3 to 5 business days for stocked modules
MOQ flexibility Low for samples Low for samples; flexible MOQ in production
Certification support Standard pre-certification Pre-certification plus custom certification assistance

How to choose: by application, not by generation

Key Takeaway: Work backwards from the deployment. The same chipset behaves very differently on an outdoor tower at −30 °C, on a factory floor at +50 °C, and in a battery-powered handheld with no airflow.

The table below maps real deployment types to modules. Use it as a starting filter, then confirm power, temperature and interface against the datasheet.

Application Recommended Module Why this module fits
Subscriber CPE, long range WLE1216VX / ZK-WLE1216VX-I 26 dBm combined output, 4×4 ac Wave 2, I-Temp for outdoor enclosures, decade-mature ath10k
WISP PtMP base station WLE3000HX / ZK-WLE3000HX 20 dBm per chain, 4×4 MU-MIMO, 9W budget sustains a high duty cycle
PtP backhaul, future-proof WLE7002E55 / ZK-WLE7002E55 5 + 6 GHz DBDC: 5 GHz for range, 6 GHz for capacity, on one module
Enterprise AP, Wi-Fi 6 WLE3000HX 4×4:4 at 5 GHz, 4.8 Gbps PHY, proven ath11k stability, 50 to 70 clients per AP
Cost-sensitive IoT gateway WLE3002HX 2×2:2 dual band, 6.6W fits 802.3af PoE, roughly 35 to 40 % lower cost than WLE3000HX
DIN-rail gateway, tight space WLTB7002E25 22 × 30 mm M.2 2230 fits enclosures Mini PCIe cannot; diplexer keeps antenna count at two
Portable battery hotspot WLTB7002E26 Ultra-low-power M.2 2230; 6 GHz service band with 2.4 GHz management fallback
Compact classroom AP WLTB7002E55 Dual 5 GHz radios separate student and staff traffic on an 80 × 80 mm board
Outdoor industrial CPE WLTE7002E25 M.2 3042 flat-mount couples thermally to the enclosure backplate; screw mount resists vibration
Fixed wireless access CPE WLTE7002E26 6 GHz backhaul up to 5.76 Gbps, 2.4 GHz for in-home coverage
WISP PtMP sector WLTE7002E55 5 GHz for client access plus 6 GHz dedicated backhaul — no separate backhaul radio
Slim enterprise AP under 25 mm WLTE7000E5 M.2 flat-mount saves about 8 mm of height versus Mini PCIe; 8.65 Gbps at 4×4:4
6 GHz-only premium AP WLTE7000E6 11.53 Gbps on 4×4:4 at 6 GHz; PCIe 3.0 x4 avoids an interface bottleneck
IoT sensor concentrator WLTE7000E2 4×4:4 at 2.4 GHz serves 60+ sensors per floor; MU-MIMO shortens the polling cycle
Warehouse robotics, long range WLE7000E2 / ZK-WLE7000E2 All four chains on 2.4 GHz for penetration through metal racking
6 GHz campus backhaul WLW3000H6 Clean 6 GHz spectrum with no DFS; 4×4:4 at 160 MHz in a compact M.2 2230

Wi-Fi 5 vs Wi-Fi 6 vs Wi-Fi 7: which generation to replace with

Key Takeaway: For most 2025–2026 replacement builds, a Wi-Fi 6 / 6E drop-in is still the practical pick — the ath11k driver ecosystem is far more mature than ath12k, and most field clients top out at Wi-Fi 6 or 6E.

When you are replacing a module, the generation decision is usually settled by three things: the driver your host already runs (ath11k for Wi-Fi 6/6E, ath12k for Wi-Fi 7), your PoE power budget, and your BOM ceiling. Wi-Fi 6/6E replacements win on all three for most production builds; a Wi-Fi 7 replacement only pays off when you need 320 MHz channels or MLO.

The practical replacement pattern is to keep the same footprint and swap generation: because the WLE3000HX (Wi-Fi 6) and the WLE7000 series (Wi-Fi 7) share the Mini PCIe form factor, the generation changes by module swap — no board redesign.

For the full decision framework — side-by-side ath11k vs ath12k comparison, PoE budget maths and worked examples — see our dedicated guide: WiFi 6 vs WiFi 7 Module Selection — When WiFi 6 / 6E Still Wins.

Deployment notes: WISP and outdoor bridge

Key Takeaway: Outdoor wireless makes three demands indoor modules were never designed for — high TX power for link budget, wide operating temperature for unventilated enclosures, and stable QSDK/OpenWrt driver support on the base station side.
  • High TX power, +20 dBm or better. Link budget is everything outdoors. Every extra dBm converts into more range, a higher modulation rate at a given distance, or margin against rain fade. That is why the WLE1216VX at 26 dBm and the WLE3000HX at 20 dBm are WISP defaults.
  • Wide operating temperature. Tower and rooftop enclosures swing hard between day and night. An I-Temp part rated −40 to +85 °C is essential; commercial parts rated to +70 °C show elevated field failure rates in tower installations.
  • QSDK and OpenWrt driver support. Most WISP base stations run QSDK or an OpenWrt derivative. Modules on the ath10k, ath11k and ath12k families integrate without custom driver work.

Subscriber CPE — WLE1216VX

The WLE1216VX has been the default WISP CPE radio for years, and the reason is link budget on the return path — the thing that keeps QAM256 stable out past 10 km.

Parameter WLE1216VX (Standard) WLE1216VX I-Temp
Chipset QCA9984 QCA9994
Form Factor Mini PCIe Mini PCIe
Frequency Band 2.4 + 5 GHz concurrent 2.4 + 5 GHz concurrent
MIMO 4×4:4 both bands 4×4:4 both bands
TX Power 20 dBm (2.4G) / 19 dBm (5G) 20 dBm (2.4G) / 19 dBm (5G)
Max Data Rate 1.73 Gbps (5 GHz, 4×4) 1.73 Gbps (5 GHz, 4×4)
Operating Temp −20 to +70 °C −40 to +85 °C
Interface PCIe 2.0 PCIe 2.0
Driver ath10k ath10k

Three things keep it dominant: the 26 dBm combined output that comes out of the CAS03 reference PA design, the I-Temp variant for tower installs, and ath10k’s maturity — 160 MHz channels, beamforming and MU-MIMO have all been exercised across a very large installed base.

PtMP base station — WLE3000HX

For WISPs moving base stations from Wi-Fi 5 to Wi-Fi 6, the WLE3000HX is the usual choice. Built on QCN9074 (PN02.1), it delivers 2.4 Gbps per 4×4 radio — roughly 40 % more than the WLE1216VX — while holding the 20 dBm per-chain TX power that sector coverage needs.

Parameter WLE3000HX / ZK-WLE3000HX
Chipset QCN9024 / QCN9074
Form Factor Mini PCIe
Frequency Band 2.4 GHz or 5 GHz, single band selectable
MIMO 4×4:4 single band
TX Power 20 dBm per chain
Max Data Rate 2.4 Gbps (5 GHz, 4×4, 160 MHz)
Power Consumption 9W typical
Interface PCIe 3.0
Driver ath11k
Operating Temp −40 to +85 °C

WLE3000HX or WLE3002HX? Both come from the QCN9074 family on PN02.1 and PN02.6. The difference is power budget — 9W against 6.6W. A base station with power to spare and a high duty cycle is better served by the WLE3000HX, which holds transmit without thermal throttling under continuous load. The WLE3002HX is for power- or thermally-constrained designs.

PtP backhaul — WLE7002E55

The WLE7002E55 is built specifically for point-to-point backhaul in a 5 + 6 GHz concurrent configuration. The QCN9274 DBDC architecture drives two independent 2×2 radios on separate bands from a single chipset.

Parameter WLE7002E55 / ZK-WLE7002E55
Chipset QCN6274 / QCN9274
Form Factor Mini PCIe
Band Configuration 5 + 6 GHz DBDC
MIMO 2×2:2 per band
TX Power 18 dBm per chain, both bands
Max Data Rate 4.32 Gbps per band (2×2, 160 MHz)
Power Consumption 8.7W
Interface PCIe 3.0
Driver ath12k

Why 5 + 6 GHz for backhaul: 5 GHz gives better range and better penetration through foliage and rain for the primary link. 6 GHz adds up to 1200 MHz of unlicensed spectrum in markets that have adopted 6 GHz rules, usable as a high-capacity overlay or a redundant path. One module replaces two radios. In a typical deployment, a 5 GHz link at 18 dBm into a 23 dBi dish reaches past 30 km at QAM256, while the 6 GHz radio carries aggregated traffic or stands by as failover.

Deployment notes: industrial embedded and robotics

Key Takeaway: Industrial embedded squeezes the module in four ways that enterprise and WISP designs do not — a 6 to 9W power ceiling, a compact footprint, no active cooling, and a custom Linux or Yocto build.
  • Power efficiency, 6 to 9W. Industrial embedded systems usually budget 15 to 30W for the whole compute plus wireless subsystem. A 9W module eats a disproportionate share. At 6.6W, the WLE3002HX leaves headroom for the application processor and sensors.
  • Compact form factor. Gateways and robot controllers often use M.2 2230 or Mini PCIe in tight enclosures. Physical size frequently decides between the two.
  • Thermal management in sealed enclosures. An IP54 or better housing has no airflow, so the module must dissipate through the PCB and the enclosure wall. The gap between 6.6W and 9W can mean 8 to 12 °C internally — enough to decide between stable operation and thermal throttling at 60 °C ambient.
  • Custom Linux and Yocto integration. Most industrial embedded runs Yocto, Buildroot or Ubuntu Core. The module needs ath10k, ath11k or ath12k support that builds into the system without proprietary binary blobs.

WLE3002HX — 6.6W low-power Mini PCIe

At 6.6W typical, the WLE3002HX is the most power-efficient high-performance Wi-Fi 6 Mini PCIe module you can buy. The Zukaka part is a direct replacement on the same QCN9074 and QCN6024 options and the same PN02.6 reference design, at the same 20 dBm per-chain TX power.

Parameter WLE3002HX / ZK-WLE3002HX
Chipset QCN6024 / QCN9024 / QCN9074
Form Factor Mini PCIe
Frequency Band 2.4 GHz or 5 GHz, single band selectable
MIMO Configuration 2×2:2
TX Power 19 dBm (2.4G) / 20 dBm (5G) per chain
Max Data Rate 573 Mbps (2.4G) / 2.4 Gbps (5G, 160 MHz)
Power Consumption 6.6W typical
Interface PCIe 3.0
Driver Support ath11k
Operating Temp −40 to +85 °C

Why 6.6W matters in practice: in a 20W gateway budget, going from 9W to 6.6W frees 2.4W for the processor or extra sensors. In a passively cooled enclosure that reduction can pull internal temperature down by 8 to 12 °C. On shift-based battery robots it buys 15 to 30 minutes of extra runtime. The part also fits an 802.3af PoE budget of 12.95W, where the 9W WLE3000HX needs 802.3at at 25.5W — a difference that shows up on the infrastructure bill as well as the module bill.

WLW3000H6 — M.2 2230 Wi-Fi 6E

The WLW3000H6 brings 6 GHz into a compact M.2 2230 Key E footprint. Pick it when you want clean 6 GHz spectrum but the product is not ready for Wi-Fi 7.

Parameter WLW3000H6 / ZK-WLW3000H6
Chipset QCN9024 / QCN9074
Form Factor M.2 2230 Key E
Frequency Band 6 GHz (Wi-Fi 6E)
MIMO Configuration 4×4:4
TX Power 20 dBm per chain
Max Data Rate 4.8 Gbps at 160 MHz
Interface PCIe 3.0
Driver Support ath11k
Operating Temp −40 to +85 °C

Choose M.2 2230 over Mini PCIe when the host processor already has native M.2 Key E support and space is tight, when the height budget needs a lower-profile part (2230 sits roughly 3 mm thinner), or when the carrier board already uses M.2 slots for other expansion. The trade-off is 2×2 against 4×4 on the smaller boards — the 2230 footprint simply has no room for the extra RF chains.

WLE7000E2 — 2.4 GHz, 4×4, heavy duty

The WLE7000E2 puts all four RF chains on 2.4 GHz. While most Wi-Fi 7 attention goes to 5 and 6 GHz, 2.4 GHz is still what gets through walls, machinery and metal enclosures in a factory.

Parameter WLE7000E2 / ZK-WLE7000E2
Chipset QCN6224 / QCN9274
Form Factor Mini PCIe
Frequency Band 2.4 GHz only
MIMO Configuration 4×4:4
TX Power 20 dBm per chain
Max Data Rate 1.15 Gbps (2.4 GHz, 4×4, 40 MHz)
Power Consumption 8W max
Interface PCIe 3.0
Driver Support ath12k

Where 4×4 on 2.4 GHz earns its keep: warehouse robotics, where AMRs need penetration through metal racking and MU-MIMO lets one module serve several robots at once; dense industrial IoT sensor hubs; and regulatory domains where 5 GHz is restricted and 2.4 GHz is the only unlicensed option available.

Form factor: Mini PCIe vs M.2 vs SDIO

Key Takeaway: Form factor decides the carrier board. M.2 is the default for new designs and is required for most Wi-Fi 6E and Wi-Fi 7 parts; Mini PCIe still dominates the installed base; SDIO covers small, low-throughput embeds.
Form Factor Typical Size Interface Best For
Mini PCIe 30 × 51 mm PCIe 2.0/3.0, USB Legacy and rugged industrial designs, Wi-Fi 5 and 6
M.2 2230 Key E 22 × 30 mm PCIe 3.0 x1, USB 2.0 Compact embedded, laptops, small gateways
M.2 3042 Key B 30 × 42 mm PCIe 3.0 x2 / x4, USB 3.0 Outdoor CPE, high-power designs needing thermal mass
SDIO Module-specific SDIO 3.0 IP cameras, sensors, hosts with no spare PCIe controller

M.2 key edges

Key edges cause more failed orders than any other single item on this list. The notch position is not cosmetic — it differs per signal set, and a module with the wrong key will not seat at all.

Key Notch Typical Signals Common Use
E-key Right PCIe x1, USB 2.0, UART, PCM, I²C Wi-Fi, Wi-Fi + BT
A-key Right, offset PCIe x1, USB 2.0 Wi-Fi + BT combos
A+E-key Both PCIe x1, USB 2.0 Fits either an A or an E slot
B-key Left PCIe x1, USB 3.0, SATA, UIM Cellular
B+M-key Both left and right PCIe x1, USB 3.0, SATA Cellular and some combos

An A+E-key module fits an E-key slot. An E-key module will not fit a B+M-key slot — and forcing it can damage the edge connector, which is a repair, not a rework.

Driver and firmware compatibility

Key Takeaway: The driver is a long-term liability, not a one-time integration task. Open-path drivers track the mainline kernel and get security fixes; a closed SDK ties your patch cadence to the vendor.
Chipset Family Linux Driver Compex / Zukaka Modules Notes
QCA9880 / QCA9882 / QCA9984 / QCA9994 ath10k WLE600VX, WLE900VX, WLE1216VX Most mature; well supported in OpenWrt and mainline Linux
QCN6024 / QCN9024 / QCN9074 ath11k WLE3000HX, WLE3002HX, WLW3000H6 Tested from kernel 5.15 through 6.6+; QSDK 11.x, OpenWrt 22.03 and later
QCN6224 / QCN6274 / QCN9274 ath12k WLE7000, WLTB7000, WLTE7000 series Newest; confirm your target kernel version before design-in

Two questions worth settling before any module swap:

  1. Is the driver in the kernel you actually ship? A module that needs an out-of-tree driver becomes a maintenance burden for the entire product life.
  2. Who owns firmware CVE response? If the device faces the open internet, plan this across the full field lifetime — typically 7 to 10 years for utility, transport and industrial products.

This table is about which driver each replacement needs. For a deeper ath11k vs ath12k comparison as a generation-selection factor, see WiFi 6 vs WiFi 7 Module Selection.

What each class will not do

Key Takeaway: Every module choice is also a set of refusals. Naming them up front prevents the classic mistake of stretching one part across every job.
Class Excels at Wrong tool for
Wi-Fi 7 radio (QCN9274) MLO reliability, 320 MHz roadmap Markets with no 6 GHz; boxes fed by a 1 Gbps uplink
Tri-band Wi-Fi 6/6E (QCN9074) Dense multi-service APs Cost-sensitive rural CPE; tiny embeds
ac Wave 2 workhorse (QCA9984/9994) High-power long range, I-Temp Multi-gig capacity; future 6 GHz offload
Tiny SDIO card Ultra-small, host-simple embeds Dense multi-gig AP service
Wi-Fi + BLE combo Band coexistence in one chassis Independent wide-channel backhaul

The pattern is consistent: capacity-focused classes get throttled by their uplink and by the market’s band plan. Range-focused classes get capped by their generation and their power table. No single module clears every column, and pretending otherwise is how products end up under-specified in the field.

ODM customization and OEM branding

Key Takeaway: Industrial designs often need a module that does not exist in any catalogue. ODM capability is the difference between adapting your product to a module and adapting the module to your product.
  • Custom PCB dimensions and connector placement. If the enclosure only has room for a rectangular module with an offset connector, the board shape can be designed while keeping the same chipset and RF design.
  • Tuned RF front-end. For a PCB trace antenna or a specific off-board antenna, the PA matching network can be tuned for optimal TX power and EVM into that load — which lowers spurious emissions and improves range.
  • Custom firmware features. ath11k and ath12k features for industrial protocols, time synchronisation or power management modes.
  • OEM branding. Custom labelling, packaging and documentation carrying your brand identity, at no additional engineering charge on production orders.

How to switch from Compex to Zukaka

Key Takeaway: Because both suppliers build on the same Qualcomm reference designs, evaluation is typically one to two weeks of bench testing rather than a redesign.
Step 1 — Identify your Compex module
Use the cross-reference tables above to find the matching Zukaka alternative. If your exact part is not listed, send the part number to the engineering team.

Step 2 — Request evaluation samples
Stocked modules ship within 3 to 5 business days. Datasheets, hardware integration guides and driver support packages come with them.

Step 3 — Validate in your hardware
Same pinout, same PCIe interface, same driver stack, same antenna requirements. Run your existing throughput, thermal and RF test plan against it. An FAE is available for integration questions.

Step 4 — Qualify and scale
Flexible production terms run from low-MOQ pilot builds to volume pricing. OEM branding is available at no additional engineering charge on production orders.

References

  1. Qualcomm — Wi-Fi 7 networking platforms and chipset documentation. qualcomm.com/products/networking
  2. Linux Wireless — ath10k driver documentation (QCA9880 / QCA9882 / QCA9984 / QCA9994). wireless.wiki.kernel.org/en/users/drivers/ath10k
  3. Linux Wireless — ath11k driver documentation (QCN6024 / QCN9024 / QCN9074). wireless.wiki.kernel.org/en/users/drivers/ath11k
  4. Linux Wireless — ath12k driver documentation (QCN6224 / QCN6274 / QCN9274). wireless.wiki.kernel.org/en/users/drivers/ath12k
  5. OpenWrt Project — Wi-Fi driver and hardware support reference. openwrt.org/docs/techref/driver.wifi
  6. PCI-SIG — M.2 specification and keying definitions. pcisig.com/specifications
  7. Wi-Fi Alliance — Wi-Fi CERTIFIED 7 and Wi-Fi 6E program documentation. wi-fi.org/discover-wi-fi
  8. FCC — Unlicensed use of the 6 GHz band. fcc.gov/6-ghz-band

Frequently Asked Questions

Q: Is Zukaka a drop-in replacement for Compex Wi-Fi modules?

Yes. Zukaka modules are built on the same Qualcomm reference designs Compex uses — CAS03, PN02.1, PN02.6, WK01.5 and WK03.2 — with the same chipsets, the same PCIe interface, the same pinouts and the same form factors. In most cases switching requires no hardware or software change.

Q: Does switching to Zukaka require driver changes?

No. Zukaka modules use the same Qualcomm chipsets and the same PCIe interface as the Compex equivalents, so they run on the same ath10k, ath11k or ath12k drivers, the same QSDK builds and the same OpenWrt configurations.

Q: Can I reuse my existing antennas?

Usually yes, provided the connector type — typically U.FL / IPEX MHF4 — and the antenna’s band coverage match. If the replacement adds 6 GHz support, the antenna must be rated for 6 GHz, otherwise the 6 GHz radio will underperform or fail band testing.

Q: Are industrial temperature versions available?

Yes. I-Temp variants specified at −40 to +85 °C are available across the Wi-Fi 5, 6, 6E and 7 ranges — for example the QCA9994-based I-Temp version of the WLE1216VX. Standard commercial grade is −20 to +70 °C.

Q: Will changing the module invalidate FCC or CE certification?

It can. Certification covers the radio as installed in the finished device. A module change usually requires at least a permissive-change assessment, and sometimes full re-testing. Pre-certification documentation and custom certification assistance are available to shorten that process.

Q: Can a WLTB7000 (M.2 2230 Key E) module be used in an M.2 3042 Key B socket?

No. The two use different keying, different PCIe lane counts — x1 against x2 or x4 — and different mechanical mounting. A 2230 module in a 3042 socket will not align with the mounting screw, and forcing it may damage the edge connector.

Q: Which M.2 modules support PCIe 3.0 x4?

The WLTE7000E2, WLTE7000E5 and WLTE7000E6 — the single-band 4×4:4 modules in M.2 3042 Key B. Their 8.65 to 11.53 Gbps PHY rates exceed what PCIe 3.0 x1 or x2 can carry, so the wider link is required to use the radio’s full speed.

Q: How much power does the WLE3002HX save versus the WLE3000HX?

The WLE3002HX draws 6.6W typical against 9W for the WLE3000HX — a 26 % reduction on the same QCN9074 architecture. The saving comes from a more efficient PA implementation on the PN02.6 reference design, not from cutting RF performance.

Q: Can I get a non-standard chipset on a standard module?

Yes, through ODM service. Chipset selection can be adjusted across the WLTB7000 and WLTE7000 series — for example supplying an industrial-temperature QCN9274 where the standard part uses QCN6274.

Q: What is the lead time for samples?

Standard sample orders ship within 3 to 5 business days for in-stock modules. Custom ODM samples require 4 to 6 weeks depending on complexity.

▶ Related Pillar Guide: For the wider picture on industrial deployment requirements — temperature range, supply longevity, EMC and form factor selection across all Wi-Fi generations — see the Industrial Wi-Fi Modules Guide. If you are hunting a specific part, the Qualcomm Mini PCIe & M.2 alternatives guide covers the QCN6274/QCN9274 Wi-Fi 7 chipset and full module mapping in detail, and the WiFi 7 series guide walks through all Mini PCIe and M.2 variants. For niche, fit-by-job selection across CPE, long-range, SDIO and Wi-Fi+BLE classes, see the Specialist Wi-Fi Modules Field Guide.

Related Blog
