2.4G Wireless Mesh Motherboard, Non-Line-of-Sight Wireless Transmission Industrial Inspection Emergency Communication Product YN300A
YN300A is a high-performance development platform designed for non-line-of-sight (NLOS) wireless transmission. The YN300A is built on a Qualcomm chipset and integrates 30dBm 5GHz 802.11a/n, with peak throughput up to 96Mbps. The platform provides fail-safe U-Boot and OpenWrt SDK open support, and can be widely used for emergency communications in firefighting, armed police, and military applications.
2.4G Wireless Mesh Motherboard – YN300A
Product Overview
YN300A is a high-performance development platform designed for non-line-of-sight (NLOS) wireless transmission, ideal for industrial inspection and emergency communication applications.
Key Overview
Target Users：System integrators, industrial inspection teams, emergency communication solution providers requiring robust NLOS wireless mesh transmission.
Core Advantages：Qualcomm chipset design with 30dBm transmit power, MANET scale > 50 nodes, relay capability > 10 hops, fail-safe U-Boot and OpenWrt SDK open support.
Typical Applications：Emergency communications for firefighting, armed police, military, water conservancy, civil defense search & rescue, emergency medical command, outdoor power and surveying, and industrial inspection.
Product Introduction
YN300A is a high-performance development platform designed for non-line-of-sight (NLOS) wireless transmission. The YN300A is built on a Qualcomm chipset and integrates 30dBm 5GHz 802.11a/n, with peak throughput up to 96Mbps. The platform provides fail-safe U-Boot and OpenWrt SDK open support, and can be widely used for emergency communications in firefighting, armed police, and military applications.
Key Features
- Water conservancy; civil defense search & rescue / emergency medical command / emergency communications vehicles
- Real-time emergency networking / emergency deployment drills / mobile wireless networking
- Ports and terminals / outdoor power and surveying / airborne and maritime transmission
- HD IP camera backhaul / computer networking data transport / wireless video transmission equipment
Product Advantages
- Elevated LOS transmission range 10–20km; ground-level LOS communications range 1.5–2km (1W)
- In high-rise residential blocks and other heavy-obstruction scenarios: full coverage beyond 16 floors; penetrates 6–10 residential buildings (1W)
Product Features
- Supports point-to-point, point-to-multipoint, multipoint-to-multipoint, and mesh modes
- MANET scale > 50 nodes; relay capability > 10 hops
- Provides fail-safe U-Boot and OpenWrt SDK open support
After-Sales Service
- Complete-device solutions available to help customers accelerate time-to-market
- Provides bare-board delivery and integrated solution technical guidance
- End-to-end customization for enclosure design, functions, and software
Technical Specifications
Interface Description
Application Scenarios
This diagram illustrates the AP management system hardware and interaction logic:
- The central mainboard is the system’s control core;
- On the right, four AP devices of different form factors are connected (e.g., wireless access points with different enclosures);
- At the bottom, terminals such as PCs, tablets, and smartphones connect to support cross-platform management;
- Arrows and lines indicate network communications and management data interactions between devices.
Key Features
- Automatic AP discovery; zero-touch AP deployment;
- Dedicated management IP allocation without consuming user DHCP addresses;
- AP group management supported; different groups can use different ESSID and other configuration profiles;
- Alias management supported: map AP MAC addresses to room numbers for more intuitive operations;
- Cross-VLAN management supported, enabling the feature without major changes to the user network;
- Centralized AP management across Layer 3 networks supported;
- JS + AJAX enables cross-platform terminal management (mobile phones, tablets, and Mac computers) via standard browsers.
Frequently Asked Questions
Q: What is the maximum transmission range of the YN300A platform?
The YN300A platform delivers elevated LOS transmission range of 10–20 km and ground-level LOS communications range of 1.5–2 km at 1W transmit power. In high-rise obstruction scenarios, it provides full coverage beyond 16 floors and penetrates 6–10 residential buildings.
Q: What wireless networking modes does the YN300A support?
The YN300A supports point-to-point, point-to-multipoint, multipoint-to-multipoint, and mesh networking modes. It features MANET scale of more than 50 nodes with relay capability exceeding 10 hops, making it ideal for large-scale ad-hoc network deployments.
Q: What development support is provided with the YN300A?
The platform provides fail-safe U-Boot and OpenWrt SDK open support, enabling customers to customize and develop their own applications. Complete-device solutions, bare-board delivery, and end-to-end customization for enclosure design, functions, and software are also available.
Q: What are the power supply requirements for the YN300A?
The YN300A accepts 7V-48V DC power input and supports 15V-48V standard/non-standard PoE. The average power consumption is approximately 10W, making it suitable for field-deployed and battery-powered applications.
Q: What are the main applications of the YN300A NLOS mesh platform?
The YN300A is widely used in emergency communications for firefighting, armed police, and military operations, as well as water conservancy monitoring, civil defense search & rescue, emergency medical command, emergency communications vehicles, outdoor power and surveying, industrial inspection, and wireless video surveillance backhaul.
